ANT TRS 700 mixing desk

Product number: ANT50

ANT (TELEFUNKEN) TRS 700 small format vintage analog mixing desk. Refurbished and recapped!

Weight: 35 kg
This item is currently not on stock.

ANT TRS 700 analogue mixer. Vintage German broadcast technology. Completely refurbished and recapped. All caps were exchanged. This compact, high quality mixer comes from the TELEFUNKEN successor ANT. It was also offered as the same desk from Tore Seem in Scandinavia. Despite its very compact dimensions, the mixer offers the quality that is known for broadcasting technology. In addition to the STUDER 169 and 961 consoles, the ANT TRS700 console is one of the very few high-quality mixers in such a compact size. The TRS700 has two channels less than the 169 or 961 consoles from STUDER, but is superior in quality  and offers more features as well as better microphone amplifiers and equalizers. A really nice and rare mixer. Ideal for people with high demandson sound and limted space in the studio. We have a flightcase for this mixer, which makes it easy and safe to send it to all destinations!

Features of the 8 mono channels:
Mic-line switching
20dB PAD switch
High quality microphone amplifier with 70dB gain via a 5-way rotary switch and a 10dB potentiometer.
High pass filter can be activated at 80Hz / 140Hz
4-band equalizer with high and low shelf and two semi-parametric mid bands.
Equalizer switchable on/off (bypass function)
4 aux-sends. Individually switchable pre / post
Panorama slider
High quality fader with solo and mute function
Insert Send-Return via 1/4" jack

Master section:
stereo bus with hi quality faders, switchable and linkable limiters in the bus. (on-off only.)
4 aux-send masters with LED meters and talkback function. Speak to individual phones!
2 aux returns. No need to use channels for FX-returns
Extra Monitor faders
Int./Ext. sources selection
TB section with tb returns
Meters bridge with stereo LED metering and internal speaker
Insert Send-Return for the master bus and the four aux-sends via 1/4" jack
